521KWh 20ft Container Storage Battery Systems For Off Grid Energy Storage Station

  • 1
  • 2

Brand Name : Soundon

Model Number : SD-ESS-1.5MW

Certification : CE,ROHS UN38.3

Place of Origin : China

MOQ : 1

Delivery Time : 35day

Packaging Details : 1PCS / Container

Rated Capacity : 521MW

Nominal power : 500KW

IP grade : IP54

Communication interface : Ethernet

Protection Level : IP54

Dimension : 20ft

Application : off-grid Energy storage station ,smart microgrid ,factories power grid supply

Contact Now



521KWh 20ft Container Storage Battery Systems For Off-grid Energy Storage Sation ​





This energy storage system with  1  set 500KW/521KWh LiFePO4 battery system ,air conditioner ,500KW PCS ,EMS ,fire fighting system .



Parameters



paramerters
Capacity  521KWh
Rated power 500KW
cycle life  >5000 cycle (90%DOD)
charge and discharge efficency 88%(under air conditioner )
charge and discharge efficency 82% (without air conditioner)
working  temperature  -20~50°C
storage temperature -40~50°C
 Battery cell
Battery type  LiFePO4
Rated voltage and capacity 3.2V50Ah
interal resistance  0.8
Voltage Range  2.7-3.65V
working temperature  charge :-10~50°C
  discharge :-30~55°C
  Max humidity 90%
cycle life  around 5000 times
Working life    more than 8 years





System feature

  •  support RS485  and RS232
  •  can support 1 high-speed Ethernet port and 4G
  • support  Modbus RTU,Modbus  TCP ,CAN protocol
  • Using high energy density and high cycle life lithium battery
  • Module design, easy to install and maintain
  • support energy storage system  peak-load shifting ,battery protection and system protection strategyand so on .
  • Independent fire control system, and support fire emergency stop, local system emergency stop, remote emergency stop function







Application



 Island micro grid, Power stations with new or distributed energy access; Small fire peak and frequency modulation power station Outdoor temporary heavy duty center, Load fluctuations of the factory, enterprise, business center etc.





Battery system



521KWh 20ft Container Storage Battery Systems For Off Grid Energy Storage Station







521KWh 20ft Container Storage Battery Systems For Off Grid Energy Storage Station
